CED Coating Electroplating Rectifier
Product Details:
- Application Electroplating
- Input Voltage 415 Volt (V)
- Output Frequency 50 Hertz (HZ)
- Output Current 50A,75A,100A,150A,200A,300A,500A,750A,1000A Ampere (amp)
- Output Voltage 300 Volt (V)
- Operation Type Semi - Automatic
- Color Blue
- Click to View more
X
CED Coating Electroplating Rectifier Price And Quantity
- 1 Unit
CED Coating Electroplating Rectifier Product Specifications
- 50A,75A,100A,150A,200A,300A,500A,750A,1000A Ampere (amp)
- 300 Volt (V)
- 415 Volt (V)
- Semi - Automatic
- 50 Hertz (HZ)
- 1 year
- Electroplating
- Blue
CED Coating Electroplating Rectifier Trade Information
- Cash in Advance (CID)
- 50 Unit Per Month
- 2-10 Days
- All India
Product Description
The CED Coating Electroplating Rectifier is a reliable and efficient solution for electroplating applications. With a blue color and semi-automatic operation type, this rectifier boasts an output frequency of 50Hz, an output voltage of 300VDC, and an output current capacity ranging from 50A to 1000A. Its CC/CV mode and downward/upward voltage ramp control make it easy to use and program. The thyristor-based design ensures stable and accurate performance, while the maximum output current programmable feature and over-current protection enhance safety. The EEPR model name/number and three-phase input voltage of 415VAC, 50Hz make it a versatile option for various electroplating needs. This rectifier comes with a 1-year warranty and is ideal for cathodic electro deposition (CED) applications such as suspension, valve actuators, brake parts, external exposed components, and auto parts.
| Control Mode | CC/ CV Mode |
| Downward Voltage Ramp Control | 0 - 100 Sec Programmable |
| Output Current Capacity | 50A,75A,100A,150A,200A,300A,500A,750A,1000ADC |
| Over Current Protection | Max. Output Current Programmable |
| Upward Voltage Ramp Control | 0 -100 Sec Programmable |
| Output Voltage | 300VDC |
| Warranty | 1 year |
| Types Of Electroplating | Cathodic Electro Deposition (CED) |
| Operating Temp. | 50 Degree Celsius |
| Frequency | 50Hz |
| Design | Thyristor Based |
| Applications | Automobile Parts |
| Model Name/Number | EEPR |
| Phase | Three Phase |
| Applications Of Cathodic Electro Deposition | Suspension,Valve Actuators,Brakes Parts,External Exposed Components,Auto Parts |
| Input Voltage | 415VAC, 50Hz |
| Types Of Ed | Cathodic |
FAQs of CED Coating Electroplating Rectifier:
Q: What is the output current capacity of this rectifier?
A: The output current capacity ranges from 50A to 1000A.Q: What is the warranty period for this product?
A: This rectifier comes with a 1-year warranty.Q: What is the input voltage of this rectifier?
A: The input voltage is 415VAC, 50Hz.Q: What is the maximum output current programmable feature?
A: The maximum output current can be programmed for enhanced safety.Q: What are the applications of cathodic electro deposition?
A: Cathodic electro deposition (CED) is ideal for suspension, valve actuators, brake parts, external exposed components, and auto parts.Tell us about your requirement
